430gsm - High Quality - Bulletproof - Kevlar fabric - filament fabric
- Code：TC-KF430F
- Material：100% Kevlar Fabric
- Weight：430gsm
- Function：Bulletproff
- Color：Yellow
- Weave：plain weave
- Width：160cm
SEND INQUIRY
Technical Data
Product |
Para aramid fabric for bullet proof |
Weight |
430gsm |
Width |
1.6m |
Warp density |
6.4/cm |
Weft density |
6.4/cm |
Warp breaking strength(N/5cm) |
13500 |
Warp breaking Elongation |
5.3% |
Weft breaking strength(N/5cm) |
14000 |
Weft breaking Elongation |
5.3% |
Aramid bulletproof fabric is a high-performance protective material. It is mainly made of para-aromatic polyamide fiber (aramid fiber), which has excellent properties such as ultra-high strength, high modulus, high temperature resistance, acid and alkali resistance, and light weight. The strength of aramid fiber is 5 to 6 times that of steel wire, and the modulus is 2 to 3 times that of steel wire or glass fiber. At the same time, its toughness is twice that of steel wire, but its weight is only about one-fifth of that of steel wire. This material can remain stable at a temperature of 560 degrees, does not decompose or melt, has good insulation properties, and has a long service life. Aramid bulletproof fabric is widely used in personal protective equipment such as bulletproof vests and bulletproof helmets, providing effective protection for soldiers, police, etc. In addition, aramid cloth also has the characteristics of insulation and heat preservation, which makes it play an important role in certain specific environments.
